Napkin Tissue Machine
The automatic napkin making machine is designed for manufacturers producing premium disposable paper products
Napkin Tissue Machine
Application
The automatic napkin making machine is designed for manufacturers producing premium disposable paper products. It is widely applied in:
- Hotels, restaurants, cafes, and catering industries
- Paper product manufacturing factories
- Supermarkets and household paper product suppliers
- Custom-printed napkin production with logos and brand designs
Features:
1. Automatic Counting & Easy Packing
- Equipped with an automatic counting system.
- Automatically counts napkins and organizes them into complete stacks for convenient packaging.
2. Accurate Folding & Uniform Size
- Reliable folding positioning system ensures precise folding.
- Produces consistently shaped napkins with uniform dimensions.
3. Customized Models Available
- Different machine models and specifications can be customized according to customers’ production requirements.
4. High-Quality Embossing System
- Steel-to-wool roller embossing technology creates clear, attractive, and durable patterns.
- Various embossing designs are available to meet different market demands.
5. Color Printing Function
- Optional color printing system is available for producing customized printed napkins with logos, patterns, or brand designs.
| Technical Parameter | Specification | Technical Parameter | Specification |
|---|---|---|---|
| Machine Type | Automatic Paper Napkin Making Machine | Product Type | Toilet Paper Napkin / Serviette |
| Production Capacity | 700 Sheets/min | Folding Type | 1/4 Fold |
| Embossing Function | Available | Color Printing Function | Available |
| Printing Type | Full Automatic Color Printing | Raw Material | Tissue Paper / Jumbo Roll Paper |
| Jumbo Roll Width | 200 mm | Paper Ply | Single Ply & Two Ply |
| Paper GSM | Single Ply: 18.5-24 g/㎡Two Ply: 14-22 g/㎡ | Open Napkin Size | 200 × 200 ±2 mm |
| Folded Napkin Size | 100 × 100 ±2 mm | Production Speed | 700 Sheets/min |
| Max. Design Speed | 800 Sheets/min | Packing Speed | 40-80 Packs/min |
| Packing Specification | 100 × 100 × 70-80 mm (Height) | Embossing Roller Type | Steel-to-Wool Roller Embossing |
| Embossing Pattern | Customized Patterns Available | Counting System | Automatic Counting |
| Control System | PLC Control | Voltage | 380 V |
| Total Power | 4.68 KW | Motor Power | 3 KW (4.02 HP) |
| Machine Weight | 1500 KG | Machine Dimension | L2840 × W2650 × H1750 mm |
| Warranty | 1 Year | Technical Support | Available |
| Place of Origin | Liaoning, China | Customized Service | Available |
