Facial Tissue Production Line
The Tissue Paper Machine is an advanced automatic production solution designed for manufacturing various types of tissue paper products, including…
Tissue Paper Machine
Features:
1. Stable and Efficient Performance
The Tissue Paper Machine is an advanced automatic production solution designed for manufacturing various types of tissue paper products, including toilet paper, facial tissue, napkins, serviettes, and other disposable paper products.
The machine uses precision transmission components and durable electrical systems to ensure:
- Smooth running
- Low noise operation
- High production efficiency
- Consistent product quality
2. Customized Solutions Available
We can provide customized tissue paper machines according to:
- Raw material width
- Paper layers
- Product size
- Folding pattern
- Printing requirements
- Production capacity
Working Process
The production process mainly includes:
Raw Paper Roll → Paper Feeding → Embossing → Printing (Optional) → Folding → Cutting → Counting → Finished Products
The machine can be equipped with different functional units to meet various tissue paper manufacturing requirements.
Technical parameter:
| Specification | Details |
|---|---|
| Finished Product Width | 170-230 mm (Customized) |
| Raw Material Width | 400-2800 mm |
| Maximum Raw Material Diameter | 1200 mm |
| Facial Tissue GSM | 2 layers: 13-17 g/m² / Single layer: 17-32 g/m² |
| Towel Paper GSM | 30-40 g/m² |
| Glue Lamination Paper | Double layers 16-17 g/m² |
| Control System | PLC Programming |
| Production Speed | 80-100 m/min |
| Slitting Device | Pneumatic Cutter |
| Edge Embossing | Optional Pneumatic Pressing |
| Vacuum System | Vortex Air Pump / Roots Blower |
| Paper Unreeling Adjustment | Stepless Adjustment |
| Unreeling Stand | 1 Unit / 2 Rolls |
| Raw Material Loading | Pneumatic Loading |
